CNC Configuration	Name	Unit	G-L1680
Travel	X/Y/Z travel	mm	2050/650/650
	Workbench area	mm	2100×600
	Distance from spindle center to column rail surface	mm	660
	Distance from spindle nose to worktable	mm	90-740
Workbench	T-slot	No.	4-18
Workbench	Max. load	kg	800
Spindle	Spindle specification		BT40/φ155
	Spindle speed	rpm	12000
	Spindle connection method		Direct drive
Feed speed	Fast movement X/Y/Z	m/min	30/48/48
Servo axis	Lead screw X/Y/Z	mm	4016/4016/4016
Servo axis	Guide railX/Y/Z	mm	X/Y/Z:45/35/45
Precision	Positioning accuracy X/Y/Z	mm	+0.01/300
Precision	Repeatability X/Y/Z	mm	+0.005/300
Tool magazine	Tool magazine capacity		BT40-24T
	Tool magazine type		Disc
	Max. diameter of the tool	mm	80/150
Machine dimension	Machine dimension	mm	465029302800

Note: Due to technological research and optimization, the company reserves the right to design and modify the technology.
